Unit injector
Pre-load ................................................................. 3-4 spanner flats (0.75 ± 0.1 mm (0.030 - 0.0040") ), please
refer to the illustration.
Tighten the adjustment screw to zero clearance against the camshaft, then turn 3-4 spanner flats.

Inlet and exhaust system
Turbocharger
TAD1640-1642GE/VE
Manufacturer/type .................................................. l3K/K29
End float, turbine shaft ........................................... max 0.13 mm (0.005")
TWD1643GE
HP-Turbo:
Manufacturer/type .................................................. Holset/HE551
End float, turbine shaft ...........................................max 0.127 mm (0.005")
LP-Turbo:
Manufacturer/type .................................................. Holset/HE82
End float, turbine shaft ...........................................max 0.152 mm (0.006")
Inlet temperature indicator
Cold engine ............................................................ Ambient temperature
Hot engine, coolant temperature 75-95°C
(167-203°F) ............................................................ max 30°C above ambient temperature
Pressure drop indicator
Pressure drop indicator warns
at a pressure drop of .............................................. 5 kPa (37.5 mm VP) ( 0.725 psi)
Boost pressure
1500 rpm 1800 rpm
TAD1640GE........................................................... 232 kPa (33.5 psi) 231 kPa (33.5 psi)
TAD1641GE........................................................... 240 kPa (34.8 psi) 252kPa (36.6 psi)
TAD1642GE........................................................... 268 kPa (38.9 psi) 262kPa (38.0 psi)
TWD1643GE .......................................................... 358 kPa (51,9 psi) 356 kPa (51.6 psi)
1800 rpm
TAD1641VE ........................................................... 193 kPa (28.0 psi)
TAD1642VE ........................................................... 225 kPa (32.6 psi)

1 Fuel hose  21193225

2 Clamp  949747

3 Sealing ring  20852764

4 Hollow screw  991048

5 Flange screw  984733

6 Rising pipe  21775773

7 Sealing ring  20899253

8 Spacer tube  21145051

9 Sealing ring  20852765

10 Sealing ring  20852762

11 Hollow screw  48634

12 Hollow screw  21159427

13 Hollow screw  21184847

14 Spacer sleeve  826652

15 Flange screw  984737

16 Fuel hose  21187595
  Replaced by:
  Fuel hose 22366851

17 Faucet  20548012

18 Protecting cover  20547976

19 Hollow screw  3595373

20 Overflow valve  21140647

21 Gasket  976931

22 Gasket  11998

23 Shim  946444

24 Clamp  982258

25 Retainer  3545508

26 Fuel hose  21452472

27 Cable tie  948211

28 Bracket  21132217

29 Flange screw  984742

30 Fuel filter housing  21168827
  Replaced by:
  Fuel filter housing 22035823

31 Tandem pump  20902698

32 Retainer  20885497
